| Verstärkersektion |
Channel |
7.2 |
| Rated Output Power (1kHz, 1ch driven) |
170 W (4 Ohm, 0,9% THD) |
| Rated Output Power (20Hz-20kHz, 2ch driven) |
110 W (8 Ohm, 0,06% THD) |
| Maximum Effective Output Power (1kHz, 1ch driven) (JEITA) |
165 W (8 Ohm, 10% THD) |
| Dynamic Power per Channel (8/6/4/2 ohms) |
135 / 165 / 210 / 280 W |
| Surround Sound Ausstattung |
CINEMA DSP |
Ja (3D) |
| DSP Programs |
23 |
| Dialog Level Adjustment |
Ja |
| Virtual Presence Speaker |
Ja |
| Surround Sound Processing |
Virtual Surround Back Speaker |
Ja |
| Surround Sound Ausstattung |
Dialogue Lift |
Ja (keine Presence Speaker nötig) |
| SILENT CINEMA / Virtual CINEMA DSP |
Ja (Virtual CINEMA FRONT) |
| Surround Sound Processing |
Dolby Atmos |
Ja |
| Surround Sound Ausstattung |
Dolby TrueHD |
Ja |
| Dolby Digital Plus |
Ja |
| Dolby Pro Logic IIx |
Ja |
| Surround Sound Processing |
DTS:X |
Ja |
| Surround Sound Ausstattung |
DTS-HD Master Audio |
Ja |
| Audio Ausstattung |
Pure Direct |
Ja (mit Video on mode) |
| Compressed Music Enhancer |
Ja |
| High-resolution Music Enhancer |
Ja |
| YPAO multi-point measurement |
Ja (R.S.C) |
| Audio Features |
YPAO Volume |
Ja |
| Audio Ausstattung |
Adaptive DRC (Dynamic Range Control) |
Ja |
| Initial Volume & Maximum Volume Setting |
Ja |
| A.R.T. Wedge |
Ja |
| Bi-amp capability |
Ja |
| Audio Delay |
Ja (0-500 ms) |
| 192kHz/24-bit DACs for all channels |
Ja (ESS) |
| Video Features |
4K Ultra HD Pass-through and upscaling |
Ja (4K/60p, 4:4:4) |
| Video Ausstattung |
HDMI 3D passthrough |
Ja |
| HDMI Audio Return Channel |
Ja |
| HDMI upscaling |
Ja (Analog zu HDMI / HDMI zu HDMI) |
| Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync |
Ja |
| Anschlüsse |
HDMI Input/Output |
8 (HDMI1-7: HDCP2.2 kompatibel) / 2 (HDCP2.2 kompatibel) |
| HDMI CEC |
Ja (SCENE, Device Control) |
| USB Input |
USB Memory, Tragbarer Audio Player |
| Network Port |
Ja |
| Connectivity |
Wi-Fi |
Ja (mit Wireless Direct) |
| Anschlüsse |
AirPlay |
Ja |
| Connectivity |
Bluetooth |
Ja (SBC / AAC) |
| Anschlüsse |
Front AV Input |
HDMI / USB / Analog Audio / Composite |
| Digital Audio Input/Output: Optical |
3 / 0 |
| Digital Audio Input/Output: Coaxial |
3 / 0 |
| Analog Audio Input/Output |
9 (Front 1) / 0 |
| Phono Input |
Ja |
| Component Video Input/Output |
3 / 1 |
| Composite Video Input/Output |
5 (Front 1) / 1 |
| Preout |
7.2 Kanal |
| Headphone Output |
1 |
| Radiosektion |
FM/AM Tuner |
Ja |
| Bedienung |
On-screen display |
Graphical User Interface |
| SCENE |
SCENE PLUS (12 Tasten) |
| App Control |
Ja (iPhone / iPad / Android Phone / Tablet) |
| Web Browser Control |
Ja |
| Remote Control Unit |
Ja (Preset) |
| Multiroom Ausstattung |
Zone 2 Audio Output |
Preout / HDMI |
| Powered Zone |
Zone 2 |
| Zone Video Output |
HDMI / Component / Composite |
| Zone HDMI |
Ja (HDMI Zonenschaltung) |
| Zone B Output |
HDMI |
| RS-232C Interface |
Ja |
| +12V Trigger Output |
2 |
| Remote (IR) Input/Output |
1 / 1 |
| Party Mode |
Ja |
| Basics |
Standby Power Consumption (IR only) |
=0,1W |
| Auto Power Standby |
Ja |
| ECO mode |
Ja |
| Dimensions (W x H x D) |
435 x 182 x 439 mm (mit Antenne: 435 x 247 x 439 mm) |
| Weight |
14,9 kg |
