Audio Performance (Stereo line inputs)
Signal/noise ratio (A-wtd, stereo direct) - 110dB
Frequency response - 20Hz—20kHz ± 0.1dB
Video Inputs
HDMI - x7 (6 x HDMI2.0a, HDCP2.2, 1 x MHL compatible)
Video Outputs
HDMI - Z1 x2 (out1 ARC, HDMI2.0a, HDCP2.2, out 2 HDMI2.0a, HDCP2.2), Z2 x1 (HDMI2.0a, HDCP2.2)
Audio Inputs
HDMI - x7, Coax SPDIF - x4, Toslink - x2, RCA Phono - x6, 3.5mm aux,
USB input, Ethernet Client, Internet Radio, ARC (from display)
Audio Outputs
7.1.4 Pre-amp output - 12x RCA Phono & 12x XLR balanced, Zone 2 output - RCA Phono
Radio Tuner
FM / DAB / DAB+ (in appropriate markets)
Supported Surround Modes Include
Dolby Atmos, Dolby Surround, DTS:X, DTS-HD Master Audio, DTS-ES 6.1
Discrete, DTS-ES 6.1 Matrix, DTS 5.1, DTS Neural:X, DTS Virtual:X, IMAX Enhanced
General
12V Trigger x2
IR in x2
6V rSeries PSU x1
Power consumption (max) - 50W (approx. 170 BTU/ hour)
Power consumption (standby) - <0.5W
Dimensions & Weights (AV860)
W x D (in. terminals) x H (inc. feet) - 433 x 425 x 171mm
Weight (net) - 10.25kg
Weight (packed) - 14.25kg
EAN/UPC code (AV860)
5 060133 602682
