Pushing our popular ZENith even further, the advanced MK3 includes a Triple-Linear PSU with Mundorf CAPS and custom-treated SSD. Ideal for audiophiles who want a smoother, more relaxed sound with a wider soundstage.
Highlights:
- New Custom Motherboard with reduced EMI
- Dual Ethernet Ports for LAN and Streamer with dedicated isolation transformers
- Innovative Triple-Linear Power Supply with ultra-low noise regulators and premium Mundorf Capacitors
- 8GB RAM with 4GB In-Memory playback
- Asymmetrical isolation feet inspired by the ZENith SE
- Ultra-low Noise USB Audio Output
- SSD Storage with newly improved vibration and EMI treatment
- New Generation Quad-core Intel CPU
- Medical-Grade Mains Filter
Funktionsumfang:
- CD Ripper, NAS and Streamer
- Internetradio, Qobuz, Tidal, Radio Paradise, Spotify
- USB - Output
- Can be used as Roon Core (Optional)
ZEN MK3
Triple-Linear Power Supply
Inspired from the high-end power supply engineering of the SE, the ZENith Mk3 benefits from new premium Mundorf capacitors with ultra-low noise regulators and a medical-grade mains filter to provide even greater audio clarity.
Custom Motherboard
Our own custom-made Innuos motherboard is completely reworked for optimised audio performance. Sources of EMI have been removed and internal clocks optimised, resulting in a “blacker” music background and enhanced realism.
Ultra-low Noise Streamer Output
Dual-ethernet ports with isolation transformers provide an ultra-low noise network connection for your streamer, removing noise from the path and improving sound quality on all network Audio.
Anti-vibration Treatment
New asymmetrical isolation feet derived from our ZENith SE plus added treatment to the chassis help to combat harmful vibration that affect a clean audio signal, with even greater treatment now applied to the SSD.
In-Memory Playback
With 4GB dedicated memory, the ZENith loads music directly to memory for playback so that it doesn’t need to engage the SSD during playback, improving sound Quality.
Technische Daten:
Digital Output:
- USB 2.0 supporting USB Audio Class 2, DoP, Native DSD and MQA
- Dedicated Ethernet Streamer Port
Connectivity:
- Ethernet: 2 x rear panel RJ45 – Bridged Gigabit Ethernet
- USB: 1x USB 2.0 (DAC), 1x USB3.0 (Backup)
Formats:
| CD Formats |
Red Book |
| Disc Compatibility |
CD, CD-R, CD-RW |
| Audio format for stored CDs |
FLAC (zero compression), WAV |
| Audio Formats Supported for streaming and playing |
WAV, AIFF, FLAC, ALAC, AAC, MP3, MQA on supported DACs |
Sample Rates:
| Sample Rates |
44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4KHz. 192kHz, 352.8KHz, 384KHz , up to DSD128 via DoP, Native DSD on selected DACs |
| Bit Depths |
16bit, 24bit, 32bit
|
User Control Interfaces:
| Web Interface |
Web Browsers from iOS, Android (4.0 and up) or up-to-date Windows and OS X browsers |
| Mobile |
App for iPhone/iPad, Android and Windows 10 |
Hardware:
| CD/DVD drive |
TEAC Slot-loading drive |
| Storage |
1TB, 2TB, 4TB SSD with Vibration and EMI Treatment |
| CPU |
Intel Quad Core N4200 |
| Memory/RAM |
8GB DDR3 Low-Voltage RAM (4GB Dedicated for RAM Playback) |
Streaming and CD Storage:
| UPnP/DLNA |
Integrated UPnP Server |
| Streaming Services |
Qobuz, Tidal, Radio Paradise, Internet Radio |
| Roon Compatibility |
Roon Core and Roon Endpoint |
| Average CD Storage Time |
5 minutes |
| CD Metadata |
FreeDB, MusicBrainz, Discogs, GD3 |
| Compatible Music Systems |
Sonos Multi-room Wireless Music System |
| DLNA/UPnP compatible streamers |
| USB DACs complying to USB Audio Class 2 |
| USB DACs supporting DSD over DoP protocol |
| Selected USB DACs supporting Native DSD |
Requirements:
| Network |
Internet connection to access album metadata when storing CDs, Internet Radio, Streaming Services and software updates |
| Network router with at least one available ethernet port |
| Premium subscription required for some streaming services such as Spotify, Qobuz and Tidal |
| Recommended App (USB Connection Only) |
Innuos Sense App, iPeng 9 (iOS), OrangeSqueeze (Android), Squeeze Control (Windows 10) |
Power:
| Mains Supply |
230V AC / 115V AC – Internal Triple-Linear Power Supply |
| Power Consumption |
12W when idle, 15W peak |
Physical:
| Dimensions |
420mm x 340mm x 83mm (W x D x H) |
| Weight |
9,0 Kg |
| In the box |
Innuos ZEN Mk3 Music Server |
| Mains Cable |
| 2m Ethernet Cable |
| Getting Started leaflet |
Angaben zur Produktsicherheit
Herstellerinformationen:
Innuos
Lote 1D, Zona Industrial Vale da Venda
Faro, Portugal, 8005-412
support@innuos.com
